Algae optimization, growth-recipe verification and process testing

  • 400 Liter LED-powered unit (4 x 100 L reactors)
  • Self-contained with automated process control
  • Cooling system for LEDs and algae medium as standard
  • Integrated CO2 supply and aeration system
  • Phototrophic or mixotrophic operation
  • Work with both freshwater and saltwater algae
  • No biofilm build-up, therefore minimal cleaning and operations downtime

Product Versions

  • LED - Series
  • SOLAR - Series
  • HBYBRID - Series

Common Product Features

  • Production Volume/Unit 1 m³ (4 x 250 L)
  • Choice of GRP or PMMA reactor shell
  • Integrated CO2 supply and aeration system
  • Automated Plant Control & Operation
  • Phototrophic & Mixotrophic operation
  • Works with freshwater & marine algae

Algae Production Everywhere

Algae Production Everywhere

Algae Production Everywhere

  • Internal high-performance LED-System enables optimal and energy–efficient algae growth
  • LED cooling system keeps < 58°C to maximize LED life (90% output after 65000 hours or ~ 15 years)
  • Algae medium is cooled to below 28°C via heat exchangers; recirculation pumps chosen to minimize sheer forces on algae cells
  • Optimized light-tube design enables steady  flow of algae medium avoiding biofilm growth on reactor walls and light tubes
  • Algae recirculation collar at reactor top cleans the air/water splash area permanently

Bright Sunshine? Perfect!

Algae Production Everywhere

Algae Production Everywhere

  • Our LCP-System collects sunlight which is transferred by optical fibers into the reactor
  • Internal reactor lighting by proprietary light-tubes enabling even light distribution within the reactor
  • Optimized light-tube design to avoid biofilm growth on reactor walls and light tubes
  • Extremely energy efficient, no external lighting or cooling required
  • Recommended for locations with high solar irradiation levels
  • Minimal maintenance downtime due to anti-biofilm design of reactor interio

Our latest Innovation!

Algae Production Everywhere

Our latest Innovation!

  • Combines the advantages of LED & SOLAR bioreactors
  • Solar LCP-power is augmented by LEDs ensuring a constant irradiation level and weather-independent algae production
  • Operates from 100% Solar to 100% LED lighting providing maximum photon flux independently from season or weather patterns
  • The LED system is activated only at insufficient sunlight levels optimizing energy consumption
  • Cooled LEDs installed at inner reactor wall & a central LED-core, sunlight supply via four LCP- light tubes

Medium Scale Bioreactors:

LED Reactor Group

Our Flagship Reactor System

  • Production volume of 5000 L per bioreactor
  • GRP reactor shell, reactor bottom with CO2 supply and aeration membrane
  • Solar powered by our LCP system, fiber optic cables for light transfer and light-tubes for even internal light distribution
  • Automated sample analysis enables truly automatic plant operation
  • Base module consists of 3 reactor lines
  • 18 Bioreactors provide a production capacity of 90 m³
  • Extremely compact footprint of approx. 1300 m²
  • Either phototrophic only or photo/mixotrophic combined
  • Fully up-scalable to higher capacity
  • No biofilm growth due to optimized reactor interior

Big Scale Production

Climate Controlled Building 1.300m² for 90m³ Capacity
